Product | Power (W) | Input Voltage | Output Voltage(VDC) | Max Output Current(A) | Package | Operating Temperature °C | Isolation | Certification | |||||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| AM1GH-1203DH30LPZ
Datasheet3D Model | 1 | 4.5~18VDC | ±3.3 | -0.152 | SIP8 | -40°C to 105°C | 3000VDC | CE/UL | |||||||||||||||||||||||||||||||
| AM1GH-1203DLPZ
Datasheet3D Model | 1 | 4.5~18VDC | ±3.3 | -0.152 | SIP8 | -40°C to 105°C | 1500VDC | CE/UL | |||||||||||||||||||||||||||||||
| AM1GH-1203SH30LPZ
Datasheet3D Model | 1 | 4.5~18VDC | 3.3 | 0.303 | SIP8 | -40°C to 105°C | 3000VDC | CE/UL | |||||||||||||||||||||||||||||||
| AM1GH-1203SLPZ
Datasheet3D Model | 1 | 4.5~18VDC | 3.3 | 0.303 | SIP8 | -40°C to 105°C | 1500VDC | CE/UL | |||||||||||||||||||||||||||||||
| AM1GH-1205DH30LPZ
Datasheet3D Model | 1 | 4.5~18VDC | ±5 | 0.1 | SIP8 | -40°C to 105°C | 3000VDC | CE/UL | |||||||||||||||||||||||||||||||
| AM1GH-1205DLPZ
Datasheet3D Model | 1 | 4.5~18VDC | ±5 | -0.1 | SIP8 | -40°C to 105°C | 1500VDC | CE/UL | |||||||||||||||||||||||||||||||
| AM1GH-1205SH30LPZ
Datasheet3D Model | 1 | 4.5~18VDC | 5 | 0.2 | SIP8 | -40°C to 105°C | 3000VDC | CE/UL | |||||||||||||||||||||||||||||||
| AM1GH-1205SLPZ
Datasheet3D Model | 1 | 4.5~18VDC | 5 | 0.2 | SIP8 | -40°C to 105°C | 1500VDC | CE/UL | |||||||||||||||||||||||||||||||
| AM1GH-1206SH30LPZ
Datasheet3D Model | 1 | 4.5~18VDC | 6 | 0.167 | SIP8 | -40°C to 105°C | 3000VDC | CE/UL | |||||||||||||||||||||||||||||||
| AM1GH-1206SLPZ
Datasheet3D Model | 1 | 4.5~18VDC | 6 | 0.167 | SIP8 | -40°C to 105°C | 1500VDC | CE/UL | |||||||||||||||||||||||||||||||
| AM1GH-1209DH30LPZ
Datasheet3D Model | 1 | 4.5~18VDC | ±9 | -0.056 | SIP8 | -40°C to 105°C | 3000VDC | CE/UL | |||||||||||||||||||||||||||||||
| AM1GH-1209DLPZ
Datasheet3D Model | 1 | 4.5~18VDC | ±9 | -0.056 | SIP8 | -40°C to 105°C | 1500VDC | CE/UL | |||||||||||||||||||||||||||||||
| AM1GH-1209SH30LPZ
Datasheet3D Model | 1 | 4.5~18VDC | 9 | 0.111 | SIP8 | -40°C to 105°C | 3000VDC | CE/UL | |||||||||||||||||||||||||||||||
| AM1GH-1209SLPZ
Datasheet3D Model | 1 | 4.5~18VDC | 9 | 0.111 | SIP8 | -40°C to 105°C | 1500VDC | CE/UL | |||||||||||||||||||||||||||||||
| AM1GH-1212DH30LPZ
Datasheet3D Model | 1 | 4.5~18VDC | ±12 | 0.042 | SIP8 | -40°C to 105°C | 3000VDC | CE/UL | |||||||||||||||||||||||||||||||
| AM1GH-1212DLPZ
Datasheet3D Model | 1 | 4.5~18VDC | ±12 | -0.042 | SIP8 | -40°C to 105°C | 1500VDC | CE/UL | |||||||||||||||||||||||||||||||
| AM1GH-1212SH30LPZ
Datasheet3D Model | 1 | 4.5~18VDC | 12 | 0.083 | SIP8 | -40°C to 105°C | 3000VDC | CE/UL | |||||||||||||||||||||||||||||||
| AM1GH-1212SLPZ
Datasheet3D Model | 1 | 4.5~18VDC | 12 | 0.083 | SIP8 | -40°C to 105°C | 1500VDC | CE/UL | |||||||||||||||||||||||||||||||
| AM1GH-1215DH30LPZ
Datasheet3D Model | 1 | 4.5~18VDC | ±15 | 0.033 | SIP8 | -40°C to 105°C | 3000VDC | CE/UL | |||||||||||||||||||||||||||||||
| AM1GH-1215DLPZ
Datasheet3D Model | 1 | 4.5~18VDC | ±15 | -0.033 | SIP8 | -40°C to 105°C | 1500VDC | CE/UL | |||||||||||||||||||||||||||||||
| AM1GH-1215SH30LPZ
Datasheet3D Model | 1 | 4.5~18VDC | 15 | 0.067 | SIP8 | -40°C to 105°C | 3000VDC | CE/UL | |||||||||||||||||||||||||||||||
| AM1GH-1215SLPZ
Datasheet3D Model | 1 | 4.5~18VDC | 15 | 0.067 | SIP8 | -40°C to 105°C | 1500VDC | CE/UL | |||||||||||||||||||||||||||||||
| AM1GH-1218SH30LPZ
Datasheet3D Model | 1 | 4.5~18VDC | 18 | 0.056 | SIP8 | -40°C to 105°C | 3000VDC | CE/UL | |||||||||||||||||||||||||||||||
| AM1GH-1218SLPZ
Datasheet3D Model | 1 | 4.5~18VDC | 18 | 0.056 | SIP8 | -40°C to 105°C | 1500VDC | CE/UL | |||||||||||||||||||||||||||||||
| AM1GH-1224DH30LPZ
Datasheet3D Model | 1 | 4.5~18VDC | ±24 | -0.021 | SIP8 | -40°C to 105°C | 3000VDC | CE/UL | |||||||||||||||||||||||||||||||
| AM1GH-1224DLPZ
Datasheet3D Model | 1 | 4.5~18VDC | ±24 | -0.021 | SIP8 | -40°C to 105°C | 1500VDC | CE/UL | |||||||||||||||||||||||||||||||
| AM1GH-1224SH30LPZ
Datasheet3D Model | 1 | 4.5~18VDC | 24 | 0.042 | SIP8 | -40°C to 105°C | 3000VDC | CE/UL | |||||||||||||||||||||||||||||||
| AM1GH-1224SLPZ
Datasheet3D Model | 1 | 4.5~18VDC | 24 | 0.042 | SIP8 | -40°C to 105°C | 1500VDC | CE/UL | |||||||||||||||||||||||||||||||
| AM1GH-1228SH30LPZ
Datasheet3D Model | 1 | 4.5~18VDC | 28 | 0.036 | SIP8 | -40°C to 105°C | 3000VDC | CE/UL | |||||||||||||||||||||||||||||||
| AM1GH-1228SLPZ
Datasheet3D Model | 1 | 4.5~18VDC | 28 | 0.036 | SIP8 | -40°C to 105°C | 1500VDC | CE/UL | |||||||||||||||||||||||||||||||
| AM1GH-2403DH30LPZ
Datasheet3D Model | 1 | 9~36VDC | ±3.3 | -0.152 | SIP8 | -40°C to 105°C | 3000VDC | CE/UL | |||||||||||||||||||||||||||||||
| AM1GH-2403DLPZ
Datasheet3D Model | 1 | 9~36VDC | ±3.3 | -0.152 | SIP8 | -40°C to 105°C | 1500VDC | CE/UL | |||||||||||||||||||||||||||||||
| AM1GH-2403SH30LPZ
Datasheet3D Model | 1 | 9~36VDC | 3.3 | 0.303 | SIP8 | -40°C to 105°C | 3000VDC | CE/UL | |||||||||||||||||||||||||||||||
| AM1GH-2403SLPZ
Datasheet3D Model | 1 | 9~36VDC | 3.3 | 0.303 | SIP8 | -40°C to 105°C | 1500VDC | CE/UL | |||||||||||||||||||||||||||||||
| AM1GH-2405DH30LPZ
Datasheet3D Model | 1 | 9~36VDC | ±5 | 0.1 | SIP8 | -40°C to 105°C | 3000VDC | CE/UL | |||||||||||||||||||||||||||||||
| AM1GH-2405DLPZ
Datasheet3D Model | 1 | 9~36VDC | ±5 | -0.1 | SIP8 | -40°C to 105°C | 1500VDC | CE/UL | |||||||||||||||||||||||||||||||
| AM1GH-2405SH30LPZ
Datasheet3D Model | 1 | 9~36VDC | 5 | 0.2 | SIP8 | -40°C to 105°C | 3000VDC | CE/UL | |||||||||||||||||||||||||||||||
| AM1GH-2405SLPZ
Datasheet3D Model | 1 | 9~36VDC | 5 | 0.2 | SIP8 | -40°C to 105°C | 1500VDC | CE/UL | |||||||||||||||||||||||||||||||
| AM1GH-2406SH30LPZ
Datasheet3D Model | 1 | 9~36VDC | 6 | 0.167 | SIP8 | -40°C to 105°C | 3000VDC | CE/UL | |||||||||||||||||||||||||||||||
| AM1GH-2406SLPZ
Datasheet3D Model | 1 | 9~36VDC | 6 | 0.167 | SIP8 | -40°C to 105°C | 1500VDC | CE/UL | |||||||||||||||||||||||||||||||
| AM1GH-2409DH30LPZ
Datasheet3D Model | 1 | 9~36VDC | ±9 | -0.056 | SIP8 | -40°C to 105°C | 3000VDC | CE/UL | |||||||||||||||||||||||||||||||
| AM1GH-2409DLPZ
Datasheet3D Model | 1 | 9~36VDC | ±9 | -0.056 | SIP8 | -40°C to 105°C | 1500VDC | CE/UL | |||||||||||||||||||||||||||||||
| AM1GH-2409SH30LPZ
Datasheet3D Model | 1 | 9~36VDC | 9 | 0.111 | SIP8 | -40°C to 105°C | 3000VDC | CE/UL | |||||||||||||||||||||||||||||||
| AM1GH-2409SLPZ
Datasheet3D Model | 1 | 9~36VDC | 9 | 0.111 | SIP8 | -40°C to 105°C | 1500VDC | CE/UL | |||||||||||||||||||||||||||||||
| AM1GH-2412DH30LPZ
Datasheet3D Model | 1 | 9~36VDC | ±12 | 0.042 | SIP8 | -40°C to 105°C | 3000VDC | CE/UL | |||||||||||||||||||||||||||||||
| AM1GH-2412DLPZ
Datasheet3D Model | 1 | 9~36VDC | ±12 | -0.042 | SIP8 | -40°C to 105°C | 1500VDC | CE/UL | |||||||||||||||||||||||||||||||
| AM1GH-2412SH30LPZ
Datasheet3D Model | 1 | 9~36VDC | 12 | 0.083 | SIP8 | -40°C to 105°C | 3000VDC | CE/UL | |||||||||||||||||||||||||||||||
| AM1GH-2412SLPZ
Datasheet3D Model | 1 | 9~36VDC | 12 | 0.083 | SIP8 | -40°C to 105°C | 1500VDC | CE/UL | |||||||||||||||||||||||||||||||
| AM1GH-2415DH30LPZ
Datasheet3D Model | 1 | 9~36VDC | ±15 | 0.033 | SIP8 | -40°C to 105°C | 3000VDC | CE/UL | |||||||||||||||||||||||||||||||
| AM1GH-2415DLPZ
Datasheet3D Model | 1 | 9~36VDC | ±15 | -0.033 | SIP8 | -40°C to 105°C | 1500VDC | CE/UL | |||||||||||||||||||||||||||||||
